Engine:
Type: 2-stroke single-cylinder air-cooled
Model: 1E45F-1
Displacement: 63ml
Max. power ouput: 1.3kw/3600rpm
Ignition system: Non-contact transistorized magneto
Starting system: Manual
Recommend power using: 0.95kw/3600rpm
Fuel tank capacity: 4.5L
Fuel consumption: 0.6L/hr
Continous operating hour: 7.5hr
Oil capacity:
Noise(7meters away): 64dB
Generator:
Rated output frequency: 50Hz
Rated output voltage: 220V
Rated power output: 0.65KVA
Max. power output: 0.75KVA
Ref datas of transportation:
Dimension (L*W*H mm): 390*325*335
N.W: 21kg
Carton dimension(L*W*H mm): 390*325*335
QTY/20GP: 730
QTY/40GP: -
QTY/40HQ: -
Standard Features:
Large-capacity air cieaner: -
Large-capacity fuel tank:-
Large-capacity muffle: -
Fuel indicator: -
Voltmeter: -
Auto voltage adjuster: .
Oil alert system: -
Circuit breaker with out fuse: -
Circuit protector: .
Opfions:
Battery tray: -
4-wheel dolly kit: -
